Carbide Short Flat Drills
Okazaki Drilling

Carbide Short Flat Drills

Workpiece material (ISO)
P · SteelM · StainlessK · Cast iron

Solid-carbide drill for machining steel, stainless steel and cast iron, for flat-bottom drilling. OK Premium coated, Ø3–12 mm in 0.1 mm diameter increments (91 catalogue items).

Ask on Line
Specifications

Sizes & part numbers

ORDER NO.ØFLUTE LOALSHANK
SDFAS030 3 mm 9 45 4
SDFAS031 3.1 mm 12 45 4
SDFAS032 3.2 mm 12 45 4
SDFAS033 3.3 mm 12 45 4
SDFAS034 3.4 mm 12 45 4
SDFAS035 3.5 mm 12 45 4
SDFAS036 3.6 mm 12 45 4
SDFAS037 3.7 mm 12 45 4
SDFAS038 3.8 mm 12 45 4
SDFAS039 3.9 mm 12 45 4
SDFAS040 4 mm 12 45 4
SDFAS041 4.1 mm 15 50 6
SDFAS042 4.2 mm 15 50 6
SDFAS043 4.3 mm 15 50 6
SDFAS044 4.4 mm 15 50 6
SDFAS045 4.5 mm 15 50 6
SDFAS046 4.6 mm 15 50 6
SDFAS047 4.7 mm 15 50 6
SDFAS048 4.8 mm 15 50 6
SDFAS049 4.9 mm 15 50 6
SDFAS050 5 mm 15 50 6
SDFAS051 5.1 mm 18 50 6
SDFAS052 5.2 mm 18 50 6
SDFAS053 5.3 mm 18 50 6
SDFAS054 5.4 mm 18 50 6
SDFAS055 5.5 mm 18 50 6
SDFAS056 5.6 mm 18 50 6
SDFAS057 5.7 mm 18 50 6
SDFAS058 5.8 mm 18 50 6
SDFAS059 5.9 mm 18 50 6
SDFAS060 6 mm 18 50 6
SDFAS061 6.1 mm 21 60 8
SDFAS062 6.2 mm 21 60 8
SDFAS063 6.3 mm 21 60 8
SDFAS064 6.4 mm 21 60 8
SDFAS065 6.5 mm 21 60 8
SDFAS066 6.6 mm 21 60 8
SDFAS067 6.7 mm 21 60 8
SDFAS068 6.8 mm 21 60 8
SDFAS069 6.9 mm 21 60 8
SDFAS070 7 mm 21 60 8
SDFAS071 7.1 mm 21 60 8
SDFAS072 7.2 mm 21 60 8
SDFAS073 7.3 mm 21 60 8
SDFAS074 7.4 mm 21 60 8
SDFAS075 7.5 mm 21 60 8
SDFAS076 7.6 mm 21 60 8
SDFAS077 7.7 mm 21 60 8
SDFAS078 7.8 mm 21 60 8
SDFAS079 7.9 mm 21 60 8
SDFAS080 8 mm 21 60 8
SDFAS081 8.1 mm 27 70 10
SDFAS082 8.2 mm 27 70 10
SDFAS083 8.3 mm 27 70 10
SDFAS084 8.4 mm 27 70 10
SDFAS085 8.5 mm 27 70 10
SDFAS086 8.6 mm 27 70 10
SDFAS087 8.7 mm 27 70 10
SDFAS088 8.8 mm 27 70 10
SDFAS089 8.9 mm 27 70 10
SDFAS090 9 mm 27 70 10
SDFAS091 9.1 mm 30 70 10
SDFAS092 9.2 mm 30 70 10
SDFAS093 9.3 mm 30 70 10
SDFAS094 9.4 mm 30 70 10
SDFAS095 9.5 mm 30 70 10
SDFAS096 9.6 mm 30 70 10
SDFAS097 9.7 mm 30 70 10
SDFAS098 9.8 mm 30 70 10
SDFAS099 9.9 mm 30 70 10
SDFAS100 10 mm 30 70 10
SDFAS101 10.1 mm 33 75 12
SDFAS102 10.2 mm 33 75 12
SDFAS103 10.3 mm 33 75 12
SDFAS104 10.4 mm 33 75 12
SDFAS105 10.5 mm 33 75 12
SDFAS106 10.6 mm 33 75 12
SDFAS107 10.7 mm 33 75 12
SDFAS108 10.8 mm 33 75 12
SDFAS109 10.9 mm 33 75 12
SDFAS110 11 mm 33 75 12
SDFAS111 11.1 mm 36 75 12
SDFAS112 11.2 mm 36 75 12
SDFAS113 11.3 mm 36 75 12
SDFAS114 11.4 mm 36 75 12
SDFAS115 11.5 mm 36 75 12
SDFAS116 11.6 mm 36 75 12
SDFAS117 11.7 mm 36 75 12
SDFAS118 11.8 mm 36 75 12
SDFAS119 11.9 mm 36 75 12
SDFAS120 12 mm 36 75 12

Get pricing & availability

Send us the size and quantity, our team replies with a quote and lead time within one business day.
