Carbide Flat Drills
Okazaki Drilling

Carbide Flat Drills

Workpiece material (ISO)
P · SteelM · StainlessK · Cast iron

Solid-carbide drill for machining steel, stainless steel and cast iron, for flat-bottom drilling. OK Premium coated, Ø1–20 mm in 0.1 mm diameter increments (191 catalogue items).

Ask on Line
Specifications

Sizes & part numbers

ORDER NO.ØFLUTE LOALSHANK
SDFA010 1 mm 4 45 3
SDFA011 1.1 mm 4 45 3
SDFA012 1.2 mm 5 45 3
SDFA013 1.3 mm 5 45 3
SDFA014 1.4 mm 5 45 3
SDFA015 1.5 mm 6 45 3
SDFA016 1.6 mm 6 45 3
SDFA017 1.7 mm 7 45 3
SDFA018 1.8 mm 7 45 3
SDFA019 1.9 mm 8 45 3
SDFA020 2 mm 8 45 4
SDFA021 2.1 mm 9 45 4
SDFA022 2.2 mm 9 45 4
SDFA023 2.3 mm 9 45 4
SDFA024 2.4 mm 10 45 4
SDFA025 2.5 mm 10 45 4
SDFA026 2.6 mm 11 45 4
SDFA027 2.7 mm 11 45 4
SDFA028 2.8 mm 11 45 4
SDFA029 2.9 mm 12 45 4
SDFA030 3 mm 12 50 6
SDFA031 3.1 mm 15 57 6
SDFA032 3.2 mm 15 57 6
SDFA033 3.3 mm 15 57 6
SDFA034 3.4 mm 15 57 6
SDFA035 3.5 mm 15 57 6
SDFA036 3.6 mm 18 60 6
SDFA037 3.7 mm 18 60 6
SDFA038 3.8 mm 18 60 6
SDFA039 3.9 mm 18 60 6
SDFA040 4 mm 18 60 6
SDFA041 4.1 mm 22 70 6
SDFA042 4.2 mm 22 70 6
SDFA043 4.3 mm 22 70 6
SDFA044 4.4 mm 22 70 6
SDFA045 4.5 mm 22 70 6
SDFA046 4.6 mm 22 70 6
SDFA047 4.7 mm 22 70 6
SDFA048 4.8 mm 22 70 6
SDFA049 4.9 mm 22 70 6
SDFA050 5 mm 22 70 6
SDFA051 5.1 mm 25 70 6
SDFA052 5.2 mm 25 70 6
SDFA053 5.3 mm 25 70 6
SDFA054 5.4 mm 25 70 6
SDFA055 5.5 mm 25 70 6
SDFA056 5.6 mm 25 70 6
SDFA057 5.7 mm 25 70 6
SDFA058 5.8 mm 25 70 6
SDFA059 5.9 mm 25 70 6
SDFA060 6 mm 25 70 6
SDFA061 6.1 mm 30 90 8
SDFA062 6.2 mm 30 90 8
SDFA063 6.3 mm 30 90 8
SDFA064 6.4 mm 30 90 8
SDFA065 6.5 mm 30 90 8
SDFA066 6.6 mm 30 90 8
SDFA067 6.7 mm 30 90 8
SDFA068 6.8 mm 30 90 8
SDFA069 6.9 mm 30 90 8
SDFA070 7 mm 30 90 8
SDFA071 7.1 mm 35 90 8
SDFA072 7.2 mm 35 90 8
SDFA073 7.3 mm 35 90 8
SDFA074 7.4 mm 35 90 8
SDFA075 7.5 mm 35 90 8
SDFA076 7.6 mm 35 90 8
SDFA077 7.7 mm 35 90 8
SDFA078 7.8 mm 35 90 8
SDFA079 7.9 mm 35 90 8
SDFA080 8 mm 35 90 8
SDFA081 8.1 mm 40 93 10
SDFA082 8.2 mm 40 93 10
SDFA083 8.3 mm 40 93 10
SDFA084 8.4 mm 40 93 10
SDFA085 8.5 mm 40 93 10
SDFA086 8.6 mm 40 93 10
SDFA087 8.7 mm 40 93 10
SDFA088 8.8 mm 40 93 10
SDFA089 8.9 mm 40 93 10
SDFA090 9 mm 40 93 10
SDFA091 9.1 mm 40 93 10
SDFA092 9.2 mm 40 93 10
SDFA093 9.3 mm 40 93 10
SDFA094 9.4 mm 40 93 10
SDFA095 9.5 mm 40 93 10
SDFA096 9.6 mm 40 93 10
SDFA097 9.7 mm 40 93 10
SDFA098 9.8 mm 40 93 10
SDFA099 9.9 mm 40 93 10
SDFA100 10 mm 40 93 10
SDFA101 10.1 mm 45 100 10
SDFA102 10.2 mm 45 100 10
SDFA103 10.3 mm 45 100 10
SDFA104 10.4 mm 45 100 10
SDFA105 10.5 mm 45 100 10
SDFA106 10.6 mm 45 100 10
SDFA107 10.7 mm 45 100 10
SDFA108 10.8 mm 45 100 10
SDFA109 10.9 mm 45 100 10
SDFA110 11 mm 45 100 10
SDFA111 11.1 mm 50 110 12
SDFA112 11.2 mm 50 110 12
SDFA113 11.3 mm 50 110 12
SDFA114 11.4 mm 50 110 12
SDFA115 11.5 mm 50 110 12
SDFA116 11.6 mm 50 110 12
SDFA117 11.7 mm 50 110 12
SDFA118 11.8 mm 50 110 12
SDFA119 11.9 mm 50 110 12
SDFA120 12 mm 50 110 12
SDFA121 12.1 mm 55 110 12
SDFA122 12.2 mm 55 110 12
SDFA123 12.3 mm 55 110 12
SDFA124 12.4 mm 55 110 12
SDFA125 12.5 mm 55 110 12
SDFA126 12.6 mm 55 110 12
SDFA127 12.7 mm 55 110 12
SDFA128 12.8 mm 55 110 12
SDFA129 12.9 mm 55 110 12
SDFA130 13 mm 55 110 12
SDFA131 13.1 mm 58 110 12
SDFA132 13.2 mm 58 110 12
SDFA133 13.3 mm 58 110 12
SDFA134 13.4 mm 58 110 12
SDFA135 13.5 mm 58 110 12
SDFA136 13.6 mm 58 110 12
SDFA137 13.7 mm 58 110 12
SDFA138 13.8 mm 58 110 12
SDFA139 13.9 mm 58 110 12
SDFA140 14 mm 58 110 12
SDFA141 14.1 mm 60 120 16
SDFA142 14.2 mm 60 120 16
SDFA143 14.3 mm 60 120 16
SDFA144 14.4 mm 60 120 16
SDFA145 14.5 mm 60 120 16
SDFA146 14.6 mm 60 120 16
SDFA147 14.7 mm 60 120 16
SDFA148 14.8 mm 60 120 16
SDFA149 14.9 mm 60 120 16
SDFA150 15 mm 60 120 16
SDFA151 15.1 mm 65 120 16
SDFA152 15.2 mm 65 120 16
SDFA153 15.3 mm 65 120 16
SDFA154 15.4 mm 65 120 16
SDFA155 15.5 mm 65 120 16
SDFA156 15.6 mm 65 120 16
SDFA157 15.7 mm 65 120 16
SDFA158 15.8 mm 65 120 16
SDFA159 15.9 mm 65 120 16
SDFA160 16 mm 65 120 16
SDFA161 16.1 mm 65 130 16
SDFA162 16.2 mm 65 130 16
SDFA163 16.3 mm 65 130 16
SDFA164 16.4 mm 65 130 16
SDFA165 16.5 mm 65 130 16
SDFA166 16.6 mm 65 130 16
SDFA167 16.7 mm 65 130 16
SDFA168 16.8 mm 65 130 16
SDFA169 16.9 mm 65 130 16
SDFA170 17 mm 65 130 16
SDFA171 17.1 mm 70 130 16
SDFA172 17.2 mm 70 130 16
SDFA173 17.3 mm 70 130 16
SDFA174 17.4 mm 70 130 16
SDFA175 17.5 mm 70 130 16
SDFA176 17.6 mm 70 130 16
SDFA177 17.7 mm 70 130 16
SDFA178 17.8 mm 70 130 16
SDFA179 17.9 mm 70 130 16
SDFA180 18 mm 70 130 16
SDFA181 18.1 mm 75 150 20
SDFA182 18.2 mm 75 150 20
SDFA183 18.3 mm 75 150 20
SDFA184 18.4 mm 75 150 20
SDFA185 18.5 mm 75 150 20
SDFA186 18.6 mm 75 150 20
SDFA187 18.7 mm 75 150 20
SDFA188 18.8 mm 75 150 20
SDFA189 18.9 mm 75 150 20
SDFA190 19 mm 75 150 20
SDFA191 19.1 mm 80 150 20
SDFA192 19.2 mm 80 150 20
SDFA193 19.3 mm 80 150 20
SDFA194 19.4 mm 80 150 20
SDFA195 19.5 mm 80 150 20
SDFA196 19.6 mm 80 150 20
SDFA197 19.7 mm 80 150 20
SDFA198 19.8 mm 80 150 20
SDFA199 19.9 mm 80 150 20
SDFA200 20 mm 80 150 20

Get pricing & availability

Send us the size and quantity, our team replies with a quote and lead time within one business day.
