3-flute solid-carbide square end mill for machining aluminium and other non-ferrous metals, for high-efficiency roughing. Available uncoated or DLC-coated, Ø6–20 mm in 2 mm diameter increments (12 catalogue items).
Widen a range or clear a field. Need a size not listed? Request a quote →
| ORDER NO. | FLUTES | Ø | FLUTE L | OAL | SHANK | COATING |
|---|---|---|---|---|---|---|
| SRE3-060 | 3 | 6 mm | 15 | 50 | 6 | Uncoated |
| SRE3D060 | 3 | 6 mm | 15 | 50 | 6 | DLC |
| SRE3-080 | 3 | 8 mm | 20 | 60 | 8 | Uncoated |
| SRE3D080 | 3 | 8 mm | 20 | 60 | 8 | DLC |
| SRE3-100 | 3 | 10 mm | 25 | 70 | 10 | Uncoated |
| SRE3D100 | 3 | 10 mm | 25 | 70 | 10 | DLC |
| SRE3-120 | 3 | 12 mm | 30 | 75 | 12 | Uncoated |
| SRE3D120 | 3 | 12 mm | 30 | 75 | 12 | DLC |
| SRE3-160 | 3 | 16 mm | 36 | 90 | 16 | Uncoated |
| SRE3D160 | 3 | 16 mm | 36 | 90 | 16 | DLC |
| SRE3-200 | 3 | 20 mm | 45 | 105 | 20 | Uncoated |
| SRE3D200 | 3 | 20 mm | 45 | 105 | 20 | DLC |
Send us the size and quantity, our team replies with a quote and lead time within one business day.
